DisplayPort 1.2 Male to HDMI Female 4Kx2K@60HZ Adapter, Black

DisplayPort 1.2 Male to HDMI Female 4Kx2K@60HZ Adapter, Black - Image 2

DisplayPort 1.2 Male to HDMI Female 4Kx2K@60HZ Adapter, Black

$19.80

Support DisplayPort input, HDMI output
Compliant with DP1.2 specification，and downward compatible with lower versions
Support HDMI resolution up to 4kx2k@60HZ
Available lengths: 100±15mm

SKU: PG-DPM-HDMIF-4K60 Categories: DisplayPort Adapters, DisplayPort Cables and Adapters

Additional information
Specifications

Additional information

Weight	0.11 lbs
Length	100±15mm
Features	• 18Gbps HDMI bandwidth • Support content protection of HDCP • EDID pass-through from PC source to display • Support 3D format and compliant with lower versions • Support power automatic management
Logistics / Shipping	Special shipping instructions, special packaging instructions, drop shipment, international shipment, will call arrangement, trucking arrangement

Specifications

Input Connector: DisplayPort Male x1
Output Connector: HDMI Female (HDMI V2.0)
HDMI Resolutions: Up to 4KX2K@60HZ
HDMI Bandwidth: 18Gbps
Operating Temperature: 0 ℃ to +45℃
Operating Humidity: 10% to 85 % RH (no condensation)
Storage Temperature: -10℃ to +70℃
Storage Humidity: 5% to 90 % RH (no condensation)
Conductor: UL 20276 [32AWG (7/0.08TC) + EAM)*5P + 32AWG (7/0.0.8TC)*5C + AEB (16/5/0.12 85%AL)
OD: 4.8mm
Electrical Test: 100%Test (Open, short, miss wire)
Contact Resistance: 2 ohm max.
Insulation Resistance: 10M ohm min.
Hi-Pot: 300V DC/10ms
Jacket: Black
Converter Unit: FCC, CE
RoHS: Yes

If subtotal of the order is less than $200, a $40 handling fee will be added to the total.
